PS40 TECH SPECS
ARTICULATED TV WALL MOUNT 40"-75"
Part of the smoothest and most reliable articulated TV wall mount range on the market, the PS40 bracket’s unique scissor arm design allows perfect parallel movement and easy one handed operation even with heavy screens. The PS40 Manual Articulated TV Wall Bracket is ideal for use either a pull and turn bracket or a maintenance bracket, with a hook on/off screen mount enabling fast and easy one person fitting, even with larger screens.
- Designed to mount onto a single stud for simple installation
- 16” stud bay mounting kit (PS-SRK) available separately for twin stud mounting, with horizontal bracket offset possible
- Universal speaker mount (USM) available separately for mounting a sound bar above or below the screen
- In built cable tie anchors for neat and simple cable management with included cable ties
- Minimum depth from wall of 55mm (2 3/16") makes it one of the thinnest brackets available
| THE PS BRACKET IS AVAILABLE IN A RANGE OF SIZES TO SUIT DIFFERENT INSTALLATIONS | ||||
|---|---|---|---|---|
| APPROX SCREEN SIZE | MAX EXTENSION FROM WALL | MAX SWIVEL | MAX WEIGHT | PRODUCT |
| 32 - 43" | 300MM (11.8") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS32 |
| 40 - 75" | 400MM (15.7") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS40 |
| 55 - 75" | 500MM (19.7") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS55 |
| 65 - 75" | 595MM (23.4") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS65 |
| 80 - 110" | 569MM (22.4") | UP TO 45° (SCREEN WIDTH DEPENDENT) |
120KG (265LBS) | PS80 |
| 110+" | VARIABLE | UP TO 45° (SCREEN WIDTH DEPENDENT) |
VARIABLE | PS80-CUSTOM |
THE ORIGINAL
CUSTOM INSTALL BRACKET
Developed specifically for the custom installation market, the PS range combines smooth screen positioning with the practical features installers need on site.
Its scissor-arm mechanism maintains parallel movement as the screen is pulled away from the wall, providing controlled positioning and easy access behind the display. A hook-on screen mount, integrated cable management and compatibility with the WB / UB wall box systems simplify installation and servicing.
With a minimum profile of just 55 mm, the PS40 can be installed directly to the wall or recessed into a compatible wall box for an even slimmer finished installation.
HAND CRAFTED IN HOUSE
TECHNICAL SPECIFICATION
| PRODUCT CODE | PS40 |
|---|---|
| BOLT PATTERN | VESA 400, 300, 200, 100 W X 400, 300, 200, 100 H |
| CABLE MANAGEMENT | IN-BUILT CABLE TIE ANCHORS & CABLE TIES INCLUDED |
| FINISH | RAL 9005 BLACK (SATIN) - CUSTOM AVAILABLE |
| MARINE SUITABLE | NO (SEE PS-M FOR MARINE USE) |
| MAX EXTENSION FROM WALL | 400MM (15 3/4") |
| MAX ROTATION | UP TO 50° EACH WAY (SCREEN WIDTH DEPENDENT) |
| MAX SCREEN DIMENSIONS | LIMITED BY WEIGHT AND DESIRED ROTATION ANGLE |
| MAX WEIGHT CAPACITY | 60KG (132LBS) |
| MIN DEPTH FROM WALL | 55MM (2 3/16") |
| MOVEMENT TYPE | MANUAL |
| OUTDOOR SUITABLE | NO (SEE PS-MO FOR OUTDOOR USE) |
| PRODUCT DIMENSIONS | 512 X 430 X 52MM (20 3/16 X 16 15/16 X 2 1/16") |
| RECOMMENDED SCREEN SIZES | 40" - 75" |
| SHIPPING INFORMATION | |
| SHIPPING DIMENSIONS | 63 x 41 x 12cm (24 x 16.1 x 4.7") |
| SHIPPING WEIGHT | 11kg (24lbs) |
